Hub Motor Stator Tester without Shaft Assembly

Introducing our advanced Stator Testing System for hub motor stators, offering high precision, adaptability, and ease. It supports AC Hipot, insulation resistance, surge, and winding resistance tests in one modular solution.

Test system Features

Intelligent: Support to connect with Internet to share the data and resources

Modular design: Independent testing module, each function has corresponding modular card

High performance: all test items can be tested at one-stopEnvironmental Testing

SPECIFICATIONS

TYPE OF TESTS	SPECIFICATIONS
Output voltage setting range/precision	AC 500ï½ÂÂ3000V : ±(2%×setting value+10V)
Breakdown current testing range/precision	0.10ï½ÂÂ20.00mA : ±(2%×display value+0.05mA)
Hipot current presetting alarm range	Max: 0.10ï½ÂÂ20.00mA; Min: 0.00ï½ÂÂ20.00mA
Hipot current/resolution	±(2%×display value+0.05 mA) : 0.01 mA
Test time range/resolution	0.5ï½ÂÂ999.9s : 0.1s/step
ARC detection	0~9 grade

KEY FEATURES

Intelligent: Supports Connecting with Internet to share the data and resources
Modular design: Independent testing module, each function has a corresponding modular card
High performance: All the tests can be done at one-stop
Strong adaptability: Surge test support to test winding over 10uH, testing voltage closed loop feedback make the accuracy higher
Easy to maintain: Support self-diagnose, remote failure diagnose and software upgrading.

What we offer

The Hub Motor Stator Tester (Without Shaft Assembly) offers precise and reliable testing of stator performance, ensuring optimal efficiency and quality. Designed for advanced EV applications, it delivers seamless fault detection and accuracy, making it an essential tool for manufacturers to maintain high production standards and enhance customer satisfaction.
